ZB6EM0B
Complete body for pilot lights, Harmony XB6, light block with body/fixing collar neon bulb 230 V
This Harmony ZB6EM0B is a light block with body/fixing collar for neon bulb 230V. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| [Us] Rated Supply Voltage | 230 V AC |
|---|---|
| Range Of Product | Harmony XB6 |
| Light Source | neon (bulb not included) |
| Light Block Supply | with resistor |
| Product Or Component Type | complete body for pilot lights |
| Connections - Terminals | Faston connectors 2.8 x 0.5 mm |
| Sale Per Indivisible Quantity | 5 |
| Device Short Name | ZB6 |
| Bulb Base | BA 9s |
| Warranty | 18 months |
| Terminals Description Iso N°1 | (X1-X2)PL |
| Net Weight | 0.003 kg |
| [Uimp] Rated Impulse Withstand Voltage | 4 kV EN 60947-1 |
| [Ui] Rated Insulation Voltage | 250 V 2)EN/IEC 60947-1 |
| Signalling Type | steady |
| Operating Position | any position |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1710010EN |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1710010EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Product Certifications |
|
| Ambient Air Temperature For Operation | -25-70 °C |
| Standards |
|
| Shock Resistance |
|
| Vibration Resistance |
|
| Ambient Air Temperature For Storage | -40-70 °C |
| Electrical Shock Protection Class | class II IEC 61140 |
| Protective Treatment | TC |
