This Harmony XB5, triple head has 1 white, 1 red and 1 black button, operates with a spring return / impulse mechanism. It is marked with "left arrow" / "right arrow" symbols. This 3-function head provides a complete 3 button interface to your machines with a single panel cut-out. It is easily installed into a standard 22mm diameter cut-outs and assembled with a collar and contact blocks to fulfill a large variety of functions. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 and IP69K. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery. Its wide range of operating temperatures from -25°C to 70°C allows versatility in usage of product.
Brand: Schneider Electric
Add to Quote CatalogueRange Of Product | Harmony XB5 |
---|---|
Mounting Diameter | 22 mm |
Type Of Operator | spring return |
Operators Description | white ''right arrow'' - black ''left arrow'' - red ''STOP'' |
Product Or Component Type | head for triple-headed push-button |
Shape Of Signaling Unit Head | rectangular |
Operator Profile | 2 flush - 1 central projecting STOP push-buttons |
Head Type | standard |
Bezel Material | dark grey plastic |
Device Short Name | XB5 |
Warranty | 18 months |
Electrical Composition Code |
|
Colour Of Marking |
|
Net Weight | 0.023 kg |
Cad Overall Height | 50 mm |
Device Presentation | basic element |
Resistance To High Pressure Washer | 7000000 Pa 55 °C 0.1 m |
Operator Profile |
|
Mechanical Durability | 1000000 cycles |
Station Name | XALD 1 cut-out |
Cad Overall Width | 30 mm |
Cad Overall Depth | 35 mm |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP1710010EN |
Sustainable Offer Status | Green Premium product |
Toxic Heavy Metal Free | Yes |
Reach Regulation | Free of Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Reach Free Of Svhc | Yes |
China Rohs Regulation | X |
Circularity Profile | ENVEOLI1710010EN |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Product Certifications |
|
Ik Degree Of Protection | IK05 IEC 50102 |
Ambient Air Temperature For Operation | -25-70 °C |
Standards |
|
Shock Resistance |
|
Vibration Resistance | 5 gn 2-500 Hz)IEC 60068-2-6 |
Ip Degree Of Protection |
|
Ambient Air Temperature For Storage | -40-70 °C |
Nema Degree Of Protection |
|
Electrical Shock Protection Class | class II IEC 61140 |
