Sale Per Indivisible Quantity | 1 |
---|---|
Range Of Product | Harmony XB4 |
Bezel Material | chromium plated metal |
Mounting Diameter | 22 mm |
Product Or Component Type | head for push-button |
Device Short Name | ZB4 |
Head Type | standard |
Warranty | 18 months |
Cap/Operator Or Lens Colour | black |
Operator Additional Information | horizontal mounting |
Operator Profile | black flush, type H012 white) |
Main Group | harsh environment |
Mechanical Durability | 3000000 cycles |
Marking | type H012 |
Type Of Operator | spring return |
Electrical Composition Code |
|
Colour Of Marking | white |
Electrical Shock Protection Class | class I IEC 61140 |
Shock Resistance | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 |
Shape Of Signaling Unit Head | round |
Vibration Resistance | 5 gn 2-500 Hz)IEC 60068-2-6 |
Cad Overall Width | 37 mm |
Cad Overall Depth | 37 mm |
Net Weight | 0.036 kg |
Cad Overall Height | 18.5 mm |
Group Of Product | flush marked type H012 |
China Rohs Regulation | X |
Circularity Profile | ENVEOLI1808008EN |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP1808008EN |
Sustainable Offer Status | Green Premium product |
Toxic Heavy Metal Free | Yes |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Reach Regulation | Free of Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Reach Free Of Svhc | Yes |
Product Certifications |
|
Ik Degree Of Protection | IK06 IEC 62262 |
Ambient Air Temperature For Operation | -40-70 °C |
Ambient Air Temperature For Storage | -40-85 °C |
Standards |
|
Nema Degree Of Protection |
|
Ip Degree Of Protection |
|
Resistance To High Pressure Washer | 90 Pa 82.5 °C |
