XENT1991
Contact block, Harmony XAC, single contact, spring return, emergency stop push button, 3NO
This Harmony XENT1991 is a pendant station contact 240V AC 3A. It is part of the range Harmony XAC pendant control stations for diameter 22mm plastic signaling units.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Contacts Type And Composition | 3 NC |
|---|---|
| Range Of Product | Harmony XAC |
| Contact Operation | slow-break |
| Type Of Operator | spring return |
| Contact Block Type | single |
| Electrical Circuit Type |
|
| Product Or Component Type | contact block |
| Contact Block Application | emergency stop push-button |
| Component Name | XENT |
| Product Compatibility | XACD |
| Warranty | 18 months |
| Connections - Terminals |
|
| Terminals Description Iso N°1 |
|
| [Ui] Rated Insulation Voltage | 400 V 3)IEC 60947-1 |
| Mechanical Durability | 3000000 cycles |
| [Ithe] Conventional Enclosed Thermal Current | 10 A |
| Short-Circuit Protection | 6 A fuse protection cartridge aM |
| Net Weight | 0.04 kg |
| Rated Operational Power In W | 3000 W AC-23B 400 V |
| [Uimp] Rated Impulse Withstand Voltage | 4 kV IEC 60947-1 |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Toxic Heavy Metal Free | Yes |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Ambient Air Temperature For Operation | -25-70 °C |
| Ambient Air Temperature For Storage | -40-70 °C |
| Overvoltage Category | class II IEC 61140 |
| Standards |
|
| Shock Resistance | 70 gn IEC 60068-2-27 |
| Vibration Resistance | 15 gn 10-500 Hz)IEC 60068-2-6 |
