VZ1 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. It is rated 32A 690V, compatible with switch types V1. VZ1 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. It is rated 32A 690V, compatible with switch types V1. A maximum of 3 VZ1 main pole modules can be attached to a switch body V1. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC) and Green Premium compliant (RoHs/Reach). Add-on main pole module for Vario switch disconnector assemblies. Same AC and DC ratings as V1 switch bodies. Other add-on modules available for V1 switch bodies , neutral (VZ11), earthing (VZ14), auxiliary contacts (VZ7, VZ20).
Brand: Schneider Electric
Add to Quote CatalogueNetwork Frequency | 50/60 Hz |
---|---|
Network Type |
|
Range Compatibility | TeSys (TeSys VARIO) switch disconnector |
Product Or Component Type | additional pole |
Performance Level | high performance |
Range | TeSys |
Contacts Type And Composition | 1 NO |
Suitability For Isolation | yes |
Poles Description | 1P |
Product Compatibility | V1 |
Device Short Name | VZ |
Warranty | 18 months |
[Ue] Rated Operational Voltage | 690 V AC 50/60 Hz |
Height | 74 mm |
[Ith] Conventional Free Air Thermal Current | 32 A |
[Ithe] Conventional Enclosed Thermal Current | 25 A |
Net Weight | 0.05 kg |
[Uimp] Rated Impulse Withstand Voltage | 8 kV |
Mounting Location |
|
Connections - Terminals |
|
Electrical Durability |
|
Mechanical Durability | 100000 cycles |
Width | 16 mm |
Tightening Torque | power circuit 2.1-2.1 N.m screw clamp terminals |
Depth | 35 mm |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP110227EN |
Sustainable Offer Status | Green Premium product |
Pvc Free | Yes |
Toxic Heavy Metal Free | Yes |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Eu Rohs Directive | Compliant |
Halogen Content Performance | Halogen free product |
Product Certifications |
|
Ambient Air Temperature For Operation | -20-50 °C |
Standards | IEC 60947-3 |
Ip Degree Of Protection | IP20 conforming to IEC 60529 |
Protective Treatment | TC |
Mechanical Robustness |
|
Fire Resistance | 960 °C IEC 60695-2-1 |
