VW3A7705 - braking resistor, Altivar, IP20, 10Ohm, 1000W

VW3A7705

Add to Quote Catalogue

Ohmic Value	10 Ohm
Range Of Product	Altivar
Product Compatibility	LXM32MC10N4 LXM32MD85N4 ATV312HD11M3 ATV312HD15M3 ATV61HD11M3X ATV61HD37N4 ATV61HD55Y ATV61HD75Y ATV61WD45N4 ATV61WD45N4C ATV71HD11M3X ATV71HD37N4 ATV71HD45Y ATV71HD55Y ATV71WD37N4
Range Compatibility	Altivar 312 Lexium 32i Lexium 52 Lexium 32 Altivar 61
[Ue] Rated Operational Voltage	24 V DC 0.1 A 250 V AC 1 A
Warranty	18 months
Continuous Power	1000 W
Height	484 mm
Protection Type	thermal protection via drive or temperature control switch 120 °C
Width	240 mm
Depth	301 mm
Average Power Available	1 kW 50 °C 1.15 kW 40 °C
Net Weight	11 kg
Electrical Connection	M6 bar wire drive terminal <= 2.5 mm² / AWG 14 temperature control switch
Contact Resistance	60 µOhm
China Rohs Regulation	X
Rohs Exemption Information	Yes
Mercury Free	Yes
Toxic Heavy Metal Free	Yes
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation	Free of Substances of Very High Concern above the threshold
California Proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach Free Of Svhc	Yes
Ambient Air Temperature For Operation	0-50 °C
Ambient Air Temperature For Storage	-25-70 °C
Ip Degree Of Protection	IP20
