TVSHWAFMK
Surge protection device, Surgelogic, HWA, mounting kit, flush
The HWA Series are suge suppressors and noise filters in a compact package. The surge suppressors use two pole spaces in a QO™ or Homeline™ load center, or NQ panelboard. HWA surge protective devices are nipple mounted, parallel connected suppressors with different voltage configurations, including delta. Square D, flush mounting kit from Surgelogic, TVSHWAFMK, allows mounting in the load center or panelboard. The surge suppressor slips into the mounted frame for easy installation.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Range Of Product | Surgelogic |
|---|---|
| Product Or Component Type | flush mounting kit |
| Device Short Name | HWA |
| Warranty | 18 months |
| Height | 178 mm |
| Width | 279.4 mm |
| Depth | 79 mm |
| Device Mounting | flush |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Eu Rohs Directive | Compliant |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
