T36FN23G7 - Starter, TeSys N, 135A, 1 NO, 100hp at 575VAC, NEMA size 4

T36FN23G7

Add to Quote Catalogue

Product Certifications	UL Listed CSA
Motor Starter Type	reversing
Thermal Overload Type	solid state Motor Logic class 10/20 45-135 A
[Uc] Control Circuit Voltage	120 V AC
Auxiliary Contact Composition	1 NO
Range Of Product	TeSys N
Nema Degree Of Protection	not rated (open device)
Nema Size	4
Poles Description	3P
Rated Power In Hp	40 HP 200 V AC 50 HP 230 V AC 100 HP 460 V AC 100 HP 575 V AC
Line Rated Current	135 A
Electrical Connection	lugs ordered separately
Control Circuit	common control circuit
Product Or Component Type	starter
Phase	3 phase
[Ue] Rated Operational Voltage	600 V AC
China Rohs Regulation	Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information	Yes
Mercury Free	Yes
Eu Rohs Directive	Compliant
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Weee	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
