QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QOB miniature circuit breaker two pole subfeed lug kit is rated 125 A at 240 VAC. Two spaces are required when this kit is used. Lugs will accept 12 AWG to 2/0 AWG aluminum or copper wire. The breaker is 3.50 inches tall, 1.494 inches wide and 2.31 inches deep. The lug kit is UL component recognized and CSA certified.
Brand: Schneider Electric
Add to Quote CatalogueRange Of Product | QO |
---|---|
[Ue] Rated Operational Voltage | 240 V AC |
Line Rated Current | 125 A |
Product Or Component Type | lug kit |
Number Of Spaces | 2 |
Phase | 2 phases |
Warranty | 18 months |
Product Certifications |
|
Height | 3.500 in |
Mounting Mode | bolt-on |
Awg Gauge | AWG 12...AWG 2/0 copper or aluminium |
Width | 1.494 in |
Depth | 2.310 in |
Number Of Poles | 2 |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Sustainable Offer Status | Green Premium product |
Toxic Heavy Metal Free | Yes |
Eu Rohs Directive | Compliant |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
Halogen Content Performance | Halogen free product |
Ambient Air Temperature For Operation |
|
