NSYTSAM638SE - Cable passages IP65, round, M63, w/o connectors, 8 entries.

NSYTSAM638SE

Add to Quote Catalogue

Range Compatibility	Spacial (Spacial S3D) compact enclosure Spacial (Spacial CRN) compact enclosure Spacial (Spacial S3CM) control enclosure Spacial (Spacial SBM) industrial box Thalassa (Thalassa PLA) suitable enclosure Thalassa (Thalassa PHD) suitable enclosure Thalassa (Thalassa PLM) compact enclosure Thalassa (Thalassa PLS) insulating modular box Spacial (Spacial S3HD) compact enclosure
Accessory / Separate Part Category	cable management accessory
Quantity Per Set	set of 10
Product Or Component Type	quick entrance plate
Device Composition	1 circular plate
Device Application	multi-purpose
Range	Spacial
Warranty	18 months
Height	real 34 mm
Mounting Support	body of enclosure cable gland plate
Material	polyamide
Cable Entry Number	4 x 5-9.2 mm 2 x 3-6.5 mm 2 x 9.6-15.9 mm
Cable Entry Number	8
Cable Outer Diameter	63.5-63.5 mm 71-71 mm
Net Weight	0.68 kg
Fixing Mode	clipped by screws
China Rohs Regulation	Product out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information	Yes
Mercury Free	Yes
Environmental Disclosure	ENVPEP100104EN
Sustainable Offer Status	Green Premium product
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Ip Degree Of Protection	IP65
