Thalassa PLA Floor standing polyester enclosure completely sealed, version PLA. 750 x 500 x 320 mm. Sealed top and bottom part assembled with side parts. 4 point door locking system with 5-mm double-bar locks. 1 door type transparent front. Polyester reinforced with fibreglass body. Protection IP 65, IK08, Grey RAL 7035.
Brand: Schneider Electric
Add to Quote CatalogueProduct Or Component Type | suitable enclosure |
---|---|
Product Name | Thalassa PLA |
Device Composition |
|
Enclosure Nominal Height | 750 mm |
Range | Thalassa |
Enclosure Mounting | floor-standing |
Enclosure Nominal Depth | 320 mm |
Device Application | multi-purpose |
Device Short Name | PLA |
Enclosure Nominal Width | 500 mm |
Product Certifications |
|
Accessibility For Operation |
|
Removable Parts |
|
Standards |
|
Door Type | Solid front |
Lock Type | 2 points lock, 5 mm double-bar |
Door Opening Side | reversible 120 °) |
Number Of Doors | 1 |
Electrical Insulation Class | class II |
Nema Degree Of Protection |
|
Body Type | sealed top and bottom part assembled with side parts |
Material | polyester reinforced with fibreglass |
Color | Gray RAL 7035) |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP110505EN |
Sustainable Offer Status | Green Premium product |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Ik Degree Of Protection | IK10 IEC 62262 plain door) |
Ambient Air Temperature For Storage | -35-90 °C |
Ip Degree Of Protection | IP65 IEC 60529 completely sealed) |
Fire Resistance | 960 °C IEC 62208 |
