Accessory / Separate Part Category | connection accessory |
---|---|
Quantity Per Set | set of 4 |
Product Or Component Type | connector |
Range | Multi9 |
Line Rated Current | 63 A |
Connections - Terminals |
|
Connection Pitch | 18 mm |
Range Compatibility | Multi9 (Multi9 C60) C60BP comb busbar |
Standards | UL 486E |
Product Certifications |
|
[Ui] Rated Insulation Voltage | 1000 V |
Color | White RAL 9001) |
Tightening Torque | 3.5-3.5 N.m |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Eu Rohs Directive | Compliant |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
