LR9D69 is a TeSys LR9D electronic overload relay from Schneider Electric to be used with a TeSys D contactor. With a thermal range 90-150A, selectable tripping class 10-20, it protects motors 55 to 75kW@400V, for unbalanced loads. LR9D69 is a TeSys LR9D electronic overload relay from Schneider Electric to be combined with a TeSys D contactor. With a thermal setting range 90-150A and a selectable tripping class 10-20, it protects unbalanced loads and motors 55 to 75kW@400V. It provides manual test & reset buttons, automatic reset, trip auxiliary contact and flag indicator, a pre-alarm circuit. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHs/Reach). Thermal overload protection, electronic type, for use with unbalanced loads (non differential), self powered (no external power supply needed). To be combined with Tesys LC1D115-D150 contactors. Light and compact, 120mm wide. Manual control with test & reset buttons, manual / automatic reset selector. High accuracy, temperature compensated to keep a precise tripping over the ambient temperature range. Selectable tripping class 10 or 20. Trip signaling with 1NO+1NC auxiliary contacts and trip flag indicator, pre-alarm signaling circuit at 105% thermal level. 90% reduction in energy dissipation compared to a thermal overload relay.
Brand: Schneider Electric
Add to Quote CatalogueSignalling Function | alarm |
---|---|
Network Type | AC |
Thermal Protection Adjustment Range | 90-150 A |
Relay Application | motor protection |
Product Or Component Type | electronic thermal overload relay |
Product Name |
|
Thermal Overload Class | class 10/20 IEC 60947-4-1 |
Range | TeSys |
[Ui] Rated Insulation Voltage |
|
Product Compatibility |
|
Device Short Name | LR9D |
Warranty | 18 months |
Network Frequency | 50-60 Hz |
Height | 118 mm |
[Ith] Conventional Free Air Thermal Current | 5 A signalling circuit |
Auxiliary Contact Composition | 1 NO + 1 NC |
Connections - Terminals |
|
Phase Failure Sensitivity | tripping in 4 s +/- 20 % IEC 60947-4-1 |
[Ue] Rated Operational Voltage | 690 V AC 0...400 Hz power circuit IEC 60947-4-1 |
Switching Capacity In Ma | 0...150 mA |
Associated Fuse Rating |
|
Net Weight | 0.9 kg |
[Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
Maximum Voltage Drop | <2.5 V closed state |
Supply Voltage Limits | 17-32 V |
Tripping Threshold |
|
Tightening Torque |
|
Control Type |
|
Mounting Support |
|
Width | 115 mm |
Depth | 125 mm |
[Us] Rated Supply Voltage | 24 V DC |
Temperature Compensation | -20-60 °C |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP080207EN |
Sustainable Offer Status | Green Premium product |
Pvc Free | Yes |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Circularity Profile | ENVEOLI100406 |
Eu Rohs Directive | Compliant |
Product Certifications |
|
Mechanical Robustness |
|
Standards |
|
Climatic Withstand | IACS E10 |
Ambient Air Temperature For Operation | -20-60 °C without derating IEC 60947-4-1 |
Dielectric Strength | 1.89 kV 50 Hz IEC 60947-1 |
Ip Degree Of Protection | IP20 conforming to IEC 60529 |
Ambient Air Temperature For Storage | -60-70 °C |
Operating Altitude | <= 6561.68 ft (2000 m) without derating |
