LA4DA1E
TeSys Deca, suppressor module, RC circuit, 24...48V AC
Specifications
| Product Or Component Type | suppressor module |
|---|---|
| Range | TeSys |
| Product Compatibility | 3P LC1D80...D150 |
| Device Short Name | LA4D |
| Warranty | 18 months |
| [Uc] Control Circuit Voltage | 24...48 V AC 50/60 Hz |
| Maximum Peak Voltage | 3 Uc |
| Mounting Mode | by screws |
| Suppressor Technology | RC circuit |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP111253EN |
| Sustainable Offer Status | Green Premium product |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Eu Rohs Directive | Compliant |
| Ambient Air Temperature For Operation | -25-55 °C |
| Ambient Air Temperature For Storage | -40-80 °C |
