TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 4NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).
Brand: Schneider Electric
Add to Quote CatalogueProduct Certifications |
|
---|---|
[Ith] Conventional Free Air Thermal Current | 10 A 50 °C |
Standards |
|
[Ue] Rated Operational Voltage | 690 V AC 25...400 Hz |
Range Compatibility |
|
Product Or Component Type | auxiliary contact block |
Product Name | TeSys K |
Range | TeSys |
Mounting Location | front |
Pole Contact Composition | 4 NC |
[Ui] Rated Insulation Voltage |
|
Auxiliary Contacts Operation | instantaneous |
Device Short Name | LA1 |
Warranty | 18 months |
Permissible Short-Time Rating |
|
Minimum Switching Current | 5 mA |
Height | 30 mm |
Non Overlap Distance | 0.5 mm |
Insulation Resistance | > 10 MOhm |
Irms Rated Making Capacity | 110 A <= 690 V AC IEC 60947 |
Associated Fuse Rating | 10 A gG <= 690 V IEC 60947 |
Net Weight | 0.045 kg |
Connections - Terminals |
|
Minimum Switching Voltage | 17 V |
Tightening Torque |
|
Width | 38 mm |
Depth | 35 mm |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP2106022 |
Sustainable Offer Status | Green Premium product |
Toxic Heavy Metal Free | Yes |
Reach Regulation | Free of Substances of Very High Concern above the threshold |
Reach Free Of Svhc | Yes |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
Eu Rohs Directive | Compliant |
Ambient Air Temperature For Operation | -25-50 °C |
Ip Degree Of Protection | IP20 conforming to IEC 60529 |
Ambient Air Temperature For Storage | -50-80 °C |
Environmental Characteristic | normal environment |
Protective Treatment | TC IEC 60068 |
Operating Altitude | 6561.68 ft (2000 m) |
