LA1DX02
Auxiliary contact block, TeSys Deca, 2NC(sealed), front mounting, screw clamp terminals
LA1DX02 is a Schneider Electric instantaneous auxiliary contact block for TeSys D contactors. It provides 2NC dust and damp protected contacts rated up to 125V AC and 30V DC, connection by screw clamp terminals. Easy clip-on mounting on front, it procures high reliability and durability. Available worldwide, it is multi-standards certified (IEC, UL, CSA, CCC) and Green Premium compliant (RoHs/Reach). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Certifications |
|
|---|---|
| Standards |
|
| [Ue] Rated Operational Voltage |
|
| Range Compatibility |
|
| Product Or Component Type | auxiliary contact block |
| Product Name | TeSys Deca |
| Range | TeSys |
| Mounting Location | front |
| Pole Contact Composition | 2 NC (sealed) |
| [Ui] Rated Insulation Voltage | 250 V IEC 60947-5-1 |
| [Ie] Rated Operational Current | 0.1 A |
| Auxiliary Contacts Operation | instantaneous |
| Device Short Name | LA1 |
| Warranty | 18 months |
| Minimum Switching Current | 1 mA |
| Height | 48 mm |
| Insulation Resistance | > 10 MOhm |
| Net Weight | 0.04 kg |
| Connections - Terminals |
|
| Minimum Switching Voltage | 5 V |
| Tightening Torque |
|
| Mechanical Durability | 5 Mcycles |
| Width | 44 mm |
| Depth | 39 mm |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP110807EN_V2 |
| Sustainable Offer Status | Green Premium product |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
| Eu Rohs Directive | Compliant |
| Ambient Air Temperature For Operation | -25-70 °C |
| Ip Degree Of Protection | IP2X conforming to IEC 60529 |
| Ambient Air Temperature For Storage | -25-70 °C |
| Environmental Characteristic | harsh environment |
| Protective Treatment | TH IEC 60068 |
