Product Certifications | UL Listed |
---|---|
Circuit Breaker Application | HACR rated |
Circuit Breaker Type | ground fault protecting class A 6 mA |
Mounting Mode | plug-in |
Short-Circuit Current | 10 kA |
Range Of Product | Homeline |
Poles Description | 2P |
Electrical Connection | screw clamp terminals |
Number Of Spaces Required | 2 |
Line Rated Current | 35 A |
Product Or Component Type | miniature circuit-breaker |
Type Of Packing | clam packaging |
[Ue] Rated Operational Voltage | 120/240 V AC |
Awg Gauge | 1 x AWG 12...AWG 4 ( aluminium ) |
Height | 4.23 in |
Tightening Torque | 4.6-4.6 N.m 2.5-10 mm² (AWG 16...AWG 14) |
Width | 2 in |
Depth | 2.98 in |
Circularity Profile | ENVEOLI1406034 |
Environmental Disclosure | ENVPEP1406034 |
Eu Rohs Directive | Under investigation |
California Proposition 65 | WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Ambient Air Temperature For Operation | 40 °C |
