Product Certifications | UL Listed |
---|---|
Circuit Breaker Application | HACR rated |
Circuit Breaker Type | standard |
Mounting Mode | plug-in |
Short-Circuit Current | 10 kA |
Range Of Product | Homeline |
Poles Description | 2P |
Electrical Connection | box lugs |
Number Of Spaces Required | 2 |
Line Rated Current | 200 A |
Product Or Component Type | miniature circuit-breaker |
Type Of Packing | consumer packaging |
[Ue] Rated Operational Voltage | 120/240 V AC |
Awg Gauge | 1 x AWG 4...300 kcmil ( aluminium/copper ) |
Warranty | Lifetime |
Height | 3.13 in |
Tightening Torque | 4.8-4.8 N.m (AWG 4...300 kcmil) |
Width | 2 in |
Depth | 2.98 in |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP1308001 |
Sustainable Offer Status | Green Premium product |
Eu Rohs Directive | Compliant |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Ambient Air Temperature For Operation | 40 °C |
