Power Consumption In W | 22 W |
---|---|
Range Of Product | Harmony GTU |
[Us] Rated Supply Voltage | 12...24 V DC power supply |
Inrush Current | 30 A |
Product Or Component Type | flat screen |
Terminal Type | touchscreen display |
Supply Voltage Limits | 10.8-28.8 V |
Provided Equipment | 1 flash card |
Height | 296 mm |
Pixel Resolution | 1024 x 768 |
Touchscreen Resolution | 1024 x 1024 |
Display Resolution | 1024 x 768 pixels XGA |
Net Weight | 4.5 kg |
Type Of Installation | indoor installation |
Depth | 67 mm |
Backlight Lifespan | 50000 hours |
Function Available | brightness sensor |
Cut-Out Dimensions | 383.5 (+ 1/- 0) x 282.5 (+ 1/- 0) mm |
Display Type | colour TFT LCD |
Touch Panel | multi touch analogue resistive |
Display Size | 15 inch |
Integrated Connection Type | USB 2.0 type A |
Display Colour | 16 million colours |
Width | 397 mm |
Type Of Cooling | natural convection |
Aspect Ratio | 4:3 |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP1311022_V2 |
Sustainable Offer Status | Green Premium product |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | X |
Circularity Profile | ENVEOLI1311022_V2 |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Ambient Air Temperature For Operation | 0-60 °C EN 61131-2 |
Standards | UL 508 |
Product Certifications |
|
Electromagnetic Compatibility | electrostatic discharge immunity testlevel 3 EN/IEC 61000-4-2 |
Ip Degree Of Protection | front panel IP66 |
Shock Resistance | 147 m/s²EN/IEC 61131-2 |
Vibration Resistance | 3.5 mm constant amplitude 5-9 Hz) EN/IEC 61131-2 |
Ambient Air Temperature For Storage | -20-60 °C |
Relative Humidity | 10-90 % non-condensing |
Nema Degree Of Protection | NEMA 4X front panel |
Operating Altitude | 6561.68 ft (2000 m) |
