GVAED101

TeSys Deca - auxiliary contact block - 2 NO

TeSys Deca auxiliary contact block, for contactors LC1D, LC1F and control relays CAD. It provides 2NO contacts rated up to 10A 690V AC, On-delay setting range 10-180s Clip-on front mounting, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach).

Brand: Schneider Electric

Add to Quote Catalogue

Specifications

Product Or Component Type	auxiliary contact block
Range	TeSys TeSys Deca
Mounting Location	front side
Pole Contact Composition	2 NO
Quantity Per Set	set of 1
Product Compatibility	GV3P GV3L
Auxiliary Contacts Operation	fault signal 1 NO
Device Short Name	GVAED
Warranty	18 months
Minimum Switching Current	5 mA
Height	11 mm
[Ith] Conventional Free Air Thermal Current	2.5 A
[Ue] Rated Operational Voltage	24...240 V AC 24...60 V DC
Protection Type	GB2CB... circuit breaker gG fuse 10 A
Net Weight	0.05 kg
[Ui] Rated Insulation Voltage	600 V UL 508 690 V IEC 60947-1 600 V CSA C22.2 No 14
Minimum Switching Voltage	17 V
Tightening Torque	1.4 N.m screw clamp terminals
Rated Operational Power In Va	300 VA 48-48 V AC-15 100000 cycles 400 VA 690-690 V AC-15 100000 cycles 500 VA 110-127 V AC-15 100000 cycles 500 VA 500-500 V AC-15 100000 cycles 650 VA 440-440 V AC-15 100000 cycles 720 VA 230-240 V AC-15 100000 cycles 850 VA 380-415 V AC-15 100000 cycles
Mechanical Durability	100000 cycles
Width	45 mm
Depth	29 mm
Rated Operational Power In W	120 W 240 V DC-13 100000 cycles 140 W 110 V DC-13 100000 cycles 140 W 24 V DC-13 100000 cycles 180 W 60 V DC-13 100000 cycles 240 W 48 V DC-13 100000 cycles
Rohs Exemption Information	Yes
Mercury Free	Yes
Environmental Disclosure	ENVPEP2207006
Sustainable Offer Status	Green Premium product
Toxic Heavy Metal Free	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
California Proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach Free Of Svhc	Yes
Weee	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation	Pro-active China RoHS declaration (out of China RoHS legal scope)
Circularity Profile	ENVEOLI2207006
Eu Rohs Directive	Compliant
Product Certifications	UKCA
Environmental Characteristic	normal environment
