The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 125 mm in height, 175 mm in width and 166 mm in depth.
Brand: Schneider Electric
Add to Quote CatalogueOutput Voltage | 12 V DC |
---|---|
Range Of Product | Easergy T300 |
Transfer Impedance | 8.5 mOhm 1 kHz |
Short-Circuit Current | 714 A IEC 60896-21 |
Battery Type | VRLA |
Internal Resistance | 20.47 mOhm IEC 60896-21 |
Product Compatibility |
|
Device Short Name | BAT24AH |
Height | 125 mm |
Net Weight | 9.8 kg |
Connector Type | M5 |
Self-Discharge Rate | 3 %, 1 month 20 °C |
Tightening Torque | 2.5 N.m |
Battery Life | 10 year(s) 20 °C Eurobat General Purpose |
Battery Capacity | 25 Ah |
Width | 175 mm |
Depth | 166 mm |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP120412EN |
Sustainable Offer Status | Green Premium product |
Toxic Heavy Metal Free | Yes |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | X |
Circularity Profile | ENVEOLI120408EN |
Eu Rohs Directive | Compliant |
Ambient Air Temperature For Operation |
|
Ambient Air Temperature For Storage | -20-60 °C |
