Range Of Product | QO |
---|---|
Product Or Component Type | Load Center |
Enclosure Type | weatherproof enclosure |
Height | 858 mm |
Short-Circuit Current | 65 kA |
Tightening Torque | main lugs 250 lb.in, AWG 4...250 kcmil, aluminium/copper |
[Ue] Rated Operational Voltage | 240 V AC |
Line Rated Current | 200 A |
Width | 362 mm |
Depth | 95 mm |
Number Of Circuits | 80 |
Number Of Spaces | 40 |
Load Center Type | PoN Convertible Mains (lugs) |
Device Composition | grounding bar included (not installed) |
Phase | 1 phase |
China Rohs Regulation | Pro-active China RoHS declaration (out of China RoHS legal scope) |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Toxic Heavy Metal Free | Yes |
Eu Rohs Directive | Compliant |
Reach Regulation | Free of Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Reach Free Of Svhc | Yes |
Product Certifications | CSA |
Nema Degree Of Protection | NEMA 3R outdoor |
Ambient Air Temperature For Operation |
|
