Range Of Product | Modicon X80 |
---|---|
Discrete Input Voltage | 24 V DC positive |
Product Or Component Type | discrete input module |
Input Type | current sink (logic positive) |
Discrete Input Type | isolated |
Discrete Input Number | 64 |
Product Specific Application | for severe environments |
Discrete Input Current | 0.6 mA |
Warranty | 18 months |
Mtbf Reliability | 510000 H |
Voltage Range | 19...30 V |
Status Led |
|
Voltage Detection Threshold |
|
Insulation Resistance | > 10 MOhm 500 V DC |
Protection Type |
|
Power Dissipation In W | 4.3 W |
Net Weight | 0.145 kg |
Paralleling Of Inputs | no |
Dc Typical Filtering Time | 4 ms |
Typical Current Consumption | 160 mA 3.3 V DC |
Input Impedance | 40000 Ohm |
Dc Maximum Filtering Time | 7 ms |
Rohs Exemption Information | Yes |
Mercury Free | Yes |
Environmental Disclosure | ENVPEP070204EN |
Sustainable Offer Status | Green Premium product |
Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
China Rohs Regulation | X |
Circularity Profile | ENVEOLI0702004EN |
Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
Ambient Air Temperature For Operation | -25-70 °C |
Shock Resistance | 30 gn |
Environmental Characteristic |
|
Dielectric Strength |
|
Vibration Resistance | 3 gn |
Directives |
|
Ambient Air Temperature For Storage | -40-85 °C |
Relative Humidity | 5-95 % -25-70 °C without condensation |
Operating Altitude |
|
Protective Treatment | conformal coating |
Ip Degree Of Protection | IP20 |
