Plug, safety switch, 60A, receptacle, Type 4X
Schneider Electric's Square D heavy duty safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock, and a color coded indicator handle. This plug serves as a Crouse-Hinds Arktite receptacle for switches in NEMA Type 1, Type 4/4X/5 stainless steel, and NEMA Type 12/3R enclosures. It is available for 30A to 100A fused or unfused switches. The receptacles are copper free cast aluminum and are epoxy coated for NEMA 4/4X/5 stainless steel safety switches. It is UL listed. This plug from Crouse-Hinds Arktite is a receptacle. This plug is used with a F safety switch with a rated current of 60A.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Or Component Type | plug |
|---|---|
| Product Destination | safety switch H(U)362WC/H(U)362DSWC/H(U)362AWC F 60-60 A |
| Warranty | 18 months |
| Product Certifications | UL Listed |
| Line Rated Current | 60 A |
| Width | 3.75 in |
| Electrical Connection | receptacle Crouse-Hinds Arktite |
| Length | 8.50 in |
| Permissible Voltage |
|
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1304031 |
| Sustainable Offer Status | Green Premium product |
| Eu Rohs Directive | Compliant |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Nema Degree Of Protection | NEMA 4X |
Documents
- Spec Sheet
- Supplemental Digest 02: Safety Switches (MAY 2023) - SD_0100CT1902_SEC-02 (pdf)
- Square D Enclosed Safety Switches Catalog - 3100CT1602 (pdf)
- Square D Safety Switches Brochure - 3100BR9801 (pdf)
- F Series Safety Switches—Neutral Assembly Replacement Instructions - files (pdf)
- Safety Switch Maintenance Instructions (30-1200 A) - files+(1) (pdf)
