plug-in electromechanical relay - 10 mm - 24 V DC - 1 CO
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This plug-in electromechanical relay is compatible with Modicon ABE7 connection sub-bases. It has 1 change over contact. It is a solid state relay with a control circuit voltage of 24V DC, a conventional free air thermal current of 5A and a maximum power dissipation per pole is 0.36W. It offers electrical durability of 500000 cycles and mechanical durability of 20 million cycles. The width pitch is 10mm. It weighs 0.01kg. It is suitable for all types of industrial applications. This product is suitable for use with Modicon ABE7P16T215, ABE7P16T230, ABE7P16T212, ABE7R16T231, ABE7P16T214, ABE7P16T230E, ABE7R16T230 and ABE7P16T210 sub-base. Modicon ABE7 means greater simplicity to rationalise wiring in your automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Control Circuit Type | DC |
|---|---|
| Range Of Product | Advantys Telefast ABE7 |
| Quantity Per Set | set of 4 |
| Product Or Component Type | plug-in electromechanical relay |
| Warranty | 18 months |
| Minimum Switching Current | 10 mA >= 5 V |
| Contacts Type And Composition | 1 C/O |
| Maximum Power Dissipation Per Pole | 0.36 W |
| Mechanical Durability | 20000000 cycles |
| Drop-Out Voltage | 2.4 V 20 °C |
| [Ith] Conventional Free Air Thermal Current | 5 A |
| Operating Rate In Hz |
|
| Product Compatibility |
|
| Associated Fuse Rating | 1 A, fast blow |
| [Uc] Control Circuit Voltage | 24 V |
| Electrical Durability |
|
| Net Weight |
|
| Electrical Reliability | 1e-008 |
| Threshold Tripping Voltage | 19.7 V 40 °C |
| [Uimp] Rated Impulse Withstand Voltage | 2.5 kV IEC 60947-1 |
| Drop-Out Current | 1 mA 20 °C |
| Maximum Switching Voltage |
|
| Width Pitch Dimension | 10 mm |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Pvc Free | Yes |
| Toxic Heavy Metal Free | Yes |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| Dielectric Strength | 2000 V IEC 60947-1 |
| Max Immunity To Microbreaks | 5 ms |
