ABR7S11
plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO
Specifications
| Control Circuit Type | DC |
|---|---|
| Range Of Product | Advantys Telefast ABE7 |
| Product Or Component Type | plug-in electromechanical relay |
| Quantity Per Set | set of 4 |
| Warranty | 18 months |
| Minimum Switching Current | 100 mA >= 5 V |
| Maximum Power Dissipation Per Pole | 0.17 W |
| [Ith] Conventional Free Air Thermal Current | 6 A |
| Associated Fuse Rating | 1 A, fast blow |
| Electrical Durability |
|
| Net Weight | 0.005 kg |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV IEC 60947-1 |
| Maximum Switching Voltage |
|
| Width Pitch Dimension | 5 mm |
| Contacts Type And Composition | 1 NO |
| Mechanical Durability | 20000000 cycles |
| Drop-Out Voltage | 2 V 20 °C |
| Operating Rate In Hz |
|
| Product Compatibility |
|
| [Uc] Control Circuit Voltage | 24 V |
| Threshold Tripping Voltage | 16.8 V 40 °C |
| Drop-Out Current | 0.5 mA 20 °C |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Pvc Free | Yes |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| China Rohs Regulation | X |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Dielectric Strength | 4000 V IEC 60947-1 |
| Max Immunity To Microbreaks | 1 ms |
