Contactor, Type L, multipole lighting, replacement unlatch coil, 110/120 VAC 50/60 Hz, 2 to 12 poles
8903L multipole lighting contactors are for lighting control applications. Contactors can switch up to 30 A fluorescent and 20 A tungsten lighting loads. The coil can be easily replaced in a 8903 LX mechanically held lighting contactor. By changing out the coil, the unlatch of the lighting contactor can be a different voltage. This will also save the cost of a whole new contactor if the coil were to fail. This unlatch coil is used in any 8903LX mechanically held lighting contactors. The coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 25 VA. This coil has a height of 1.75 inches, a width of 2.46 inches and a depth of 1.13 inches. Coil is fully encapsulated to protect it. Coil has screw clamp connections. Coil has screw clamp connections.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Accessory / Separate Part Destination | class 8903 contactor |
|---|---|
| Product Or Component Type | coil |
| Warranty | 18 months |
| [Ue] Rated Operational Voltage |
|
| Height | 44.5 mm |
| Inrush Power In Va | 180 VA |
| Width | 62.5 mm |
| Depth | 28.7 mm |
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
| Eu Rohs Directive | Under investigation |
