8903L multipole lighting contactors are for lighting control applications. Contactors can switch up to 30 A fluorescent and 20 A tungsten lighting loads. The coil can be easily replaced in a 8903 L lighting contactor. By changing out the coil, the lighting contactor can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor if the coil were to fail. This coil is used in an 8903L, 2 to 6 poles, and 8930LX, 2 to 4 poles, lighting contactors. The coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 150 VA. It has an average sealed consumption of 30 VA. This coil has a height of 2.38 inches, a width of 2.11 inches and a depth of 1.46 inches. Coil is fully encapsulated to protect it. Coil has screw clamp connections. Coil has screw clamp connections.
Brand: Schneider Electric
Add to Quote CatalogueAccessory / Separate Part Destination | class 8903 contactor |
---|---|
Product Or Component Type | coil |
Warranty | 18 months |
Average Consumption | 30 VA |
[Ue] Rated Operational Voltage |
|
Height | 60.5 mm |
Inrush Power In Va |
|
Width | 53.6 mm |
Depth | 37.1 mm |
China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information. |
Eu Rohs Directive | Under investigation |
