Pilot light, Harmony 9001SK, plastic, polycarbonate, fresnel lens, red, 30mm, LED red, 110...120V
This illuminated red push-to-test pilot light with integral LED provides an ergonomic and visual interface for your machines It is clearly distinguishable visually at a distance thanks to its illuminated head and clear color It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections Tha package dimensions are 5.08 cm (width) x 32.7 cm (length) x 12.9 cm (height) High performance International standards & certifications (Marine ABS certification, Type 1, 2, 3, 3R, 4, 6, 12 and 13)
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Range Of Product | Harmony 9001SK |
|---|---|
| Light Block Supply | direct 110...120 V AC 50/60 Hz |
| Product Or Component Type | pilot light |
| Lens Type | fresnel plastic |
| Device Short Name | 9001SK |
| Warranty | 18 months |
| [Us] Rated Supply Voltage | 110...120 V |
| [Us] Rated Supply Voltage | 110...120 V AC 50/60 Hz |
| Lens Material | polycarbonate |
| Light Source | LED |
| Mounting Diameter | 30 mm |
| Light Block Supply | via integral transformer |
| [Ith] Conventional Free Air Thermal Current | 10 A |
| Short-Circuit Protection | 10 A cartridge fuse EN/IEC 60947-5-1 |
| Shape Of Signaling Unit Head | round |
| Cap/Operator Or Lens Colour | red |
| Net Weight | 0.181 kg |
| [Uimp] Rated Impulse Withstand Voltage | 2.5 kV EN/IEC 60947-1 |
| Size | 30 mm |
| Cad Overall Height | 70 mm |
| Lens Type | fresnel |
| Connections - Terminals | screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1 |
| Light Source | Red LED |
| [Ui] Rated Insulation Voltage | 250 V 2)EN/IEC 60947-1 |
| Bezel Material | plastic |
| Light Source Colour | red |
| Operating Position | any position |
| Tightening Torque | 0.8-0.8 N.m EN/IEC 60947-1 |
| Cad Overall Width | 54 mm |
| Cad Overall Depth | 42 mm |
| Shape Of Screw Head | cross slotted |
| Supply Frequency | 50...60 Hz |
| Bulb Base | BA 9s |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1710019EN |
| Sustainable Offer Status | Green Premium product |
| Toxic Heavy Metal Free | Yes |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Reach Free Of Svhc | Yes |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1710019EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Product Certifications |
|
| Ambient Air Temperature For Operation | -25-70 °C |
| Standards |
|
| Shock Resistance | 50 gn IEC 60068-2-27 |
| Vibration Resistance | 7 gn 2-500 Hz)IEC 60068-2-6 |
| Ip Degree Of Protection | IP66 IEC 60529 |
| Ambient Air Temperature For Storage | -40-70 °C |
| Nema Degree Of Protection |
|
| Electrical Shock Protection Class | class II IEC 61140 |
| Protective Treatment | TC |
