9001SK2L - Illuminated push-button head, Harmony 9001SK, plastic, projecting, without cap, 30mm, spring return, without bulb

9001SK2L

Add to Quote Catalogue

Range Of Product	Harmony 9001SK
Product Or Component Type	head for illuminated push-button
Device Short Name	9001SK
Warranty	18 months
Product Certifications	CSA LR24590 class 3211 03 CE UL listed file E42259 CCN NKCR
Contacts Type And Composition	without contact block
Light Source	without
Operator Additional Information	without guard
Bezel Material	plastic
Nema Degree Of Protection	NEMA 1/2/3/3R/4/4X/6/12/13
Light Source	bulb not included
Light Block Supply	without supply
Mounting Diameter	30 mm
Operator Profile	projecting
Type Of Operator	spring return
Shape Of Signaling Unit Head	octagonal
Cap/Operator Or Lens Colour	without cap
Size	30 mm
Ip Degree Of Protection	IP64
Bulb Base	BA 9s
China Rohs Regulation	X
Rohs Exemption Information	Yes
Mercury Free	Yes
Environmental Disclosure	ENVPEP121005EN
Sustainable Offer Status	Green Premium product
Toxic Heavy Metal Free	Yes
Eu Rohs Directive	Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation	Free of Substances of Very High Concern above the threshold
California Proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Reach Free Of Svhc	Yes
Weee	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
