9001KR8P1G
Illuminated push-button head, Harmony 9001K, metal, mushroom 41mm, green, 30mm, 3 positions, return to center, 110-120V
This head for spring return push-button is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy It is clearly distinguishable visually at a distance thanks to clear color It is impact resistant, dust resistant, water resistant and vibration resistant, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and easily connected with control circuits High performance International standards & certifications (Marine ABS certification, IP66, Type 1, 2, 3, 3R, 4, 12 and 13)
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Operator Additional Information | screw-on plastic |
|---|---|
| Range Of Product | Harmony 9001K |
| Operator Profile | flush |
| Product Or Component Type | head for illuminated push-button |
| Device Short Name | 9001K |
| Warranty | 18 months |
| [Us] Rated Supply Voltage | 110...120 V |
| Contacts Type And Composition | without contact block |
| Bezel Material | metal |
| Operator Position Information | 3 positions |
| Mounting Diameter | 30 mm |
| Type Of Operator | spring return |
| Light Block Supply | via integral transformer |
| Operator Profile | mushroom Ø 41 mm |
| Type Of Operator | pull : spring return, center : stay put, push : spring return |
| Shape Of Signaling Unit Head | round |
| Cap/Operator Or Lens Colour | green |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP121006EN |
| Sustainable Offer Status | Green Premium product |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
