9001K2L35LRR
Complete illuminated push button, Harmony 9001K, metal, projecting, red, 30mm, spring return, LED red, 24...28V
This illuminated push-button with integral LED provides an ergonomic and visual interface for controlling your machines It is clearly distinguishable visually at a distance thanks to its illuminated head and clear color It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and is easily connected to control circuits High performance International standards & certifications ( Marine certification, IP65, Type 4, 13 and 4X)
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Light Source | Red LED |
|---|---|
| Range Of Product | Harmony 9001K |
| Mounting Diameter | 30 mm |
| Product Or Component Type | head for illuminated push-button |
| Device Short Name | 9001K |
| Warranty | 18 months |
| [Us] Rated Supply Voltage | 24...28 V |
| Contacts Type And Composition | without contact block |
| Bezel Material | metal |
| Operator Profile | red projecting, unmarked |
| Light Source Colour | red |
| Mechanical Durability | 5000000 cycles |
| Light Block Supply | direct 24...28 V AC/DC |
| Type Of Operator | spring return |
| Operator Profile | projecting |
| Operating Position | any position |
| Shape Of Signaling Unit Head | round |
| Cap/Operator Or Lens Colour | red |
| Net Weight | 0.166 kg |
| Bulb Base | BA 9s |
| China Rohs Regulation | X |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP121006EN |
| Sustainable Offer Status | Green Premium product |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Product Certifications |
|
| Ambient Air Temperature For Operation | -25-70 °C |
| Ambient Air Temperature For Storage | -40-70 °C |
| Standards |
|
| Nema Degree Of Protection |
|
| Electrical Shock Protection Class | class II IEC 61140 |
| Shock Resistance | 50 gn IEC 60068-2-27 |
| Vibration Resistance | 7 gn 2-500 Hz)IEC 60068-2-6 |
| Protective Treatment | TC |
| Ip Degree Of Protection | IP66 IEC 60529 |
