The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SG Series B contactor, an 8536SG Series B starter or an 8903SX Series B lighting contactor. This coil is rated for 440/480 VAC 50/60 Hz. The inrush power of this coil is 1300 VA. It has an average sealed consumption of 14 VA. Coil has screw clamp connections.
Brand: Schneider Electric
Add to Quote CatalogueAccessory / Separate Part Category | replacement part |
---|---|
Product Or Component Type | coil |
Warranty | 18 months |
[Ue] Rated Operational Voltage | 440/480 V AC 60 Hz |
Nema Size | 5 |
Product Compatibility | motor starter class 8502 type SG |
Eu Rohs Directive | Not applicable, out of EU RoHS legal scope |
