3109632050
NEMA Motor Starter, Type S, replacement coil, Series B, 110/120VAC 50/60Hz, NEMA size 5 starter and 8903SX lighting
The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SG Series B contactor, an 8536SG Series B starter or an 8903SX Series B lighting contactor. This coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 1300 VA. It has an average sealed consumption of 14 VA. Coil has screw clamp connections.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Product Or Component Type | coil |
|---|---|
| Warranty | 18 months |
| [Ue] Rated Operational Voltage | 110/120 V AC 50/60 Hz |
| Nema Size | 5 |
| Product Compatibility |
|
| Eu Rohs Directive | Not applicable, out of EU RoHS legal scope |
Documents
- Spec Sheet
- Square D NEMA Contactors and Starters Accessories Catalog - 9999CT9701R0817 (pdf)
- Digest Catalog 16: NEMA and Definite Purpose Contactors and Starters (SEP 2022) - 0100CT1901_SEC-16_SEP2022 (pdf)
- AC Magnetic Contactors and Starters - 30072-013-103_01 (pdf)
- AC Magnetic Starters with TeSys T MMS, Size 5 Installation Instructions - 30072-452-70+Rev.01 (pdf)
- 8502SG and 8536SG, 2- and 3-Pole AC Magnetic Contactors and 3-Pole AC Magnetic Starters with Motor Logic; Plus Solid-State Overload Relay, Size 5, Series A, Form B Installation Instructions - 30072-013-110 (pdf)
