discrete input module Modicon Momentum - 16 Input 100..120 V AC
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base AC module offers 2 groups of 8 inputs, conforming to IEC 1131-2 type 2 with positive discrete input logic. It is a module with discrete input voltage of 120V AC. There is an isolation between group, channels and bus at 1780V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.284kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
Brand: Schneider Electric
Add to Quote CatalogueSpecifications
| Group Of Channels | 2 groups of 8 inputs |
|---|---|
| Range Of Product | Modicon Momentum automation platform |
| Discrete Input Voltage | 120 V AC |
| Product Or Component Type | discrete inputs base AC |
| Discrete Input Number | 16 IEC 1131-2 Type 2 |
| Protective Treatment | TC |
| Warranty | 18 months |
| Network Frequency | 47...63 Hz |
| Height | 141.5 mm |
| Terminals Description Plc N°1 |
|
| Isolation Between Channels And Bus | 1780 V AC |
| Current Consumption | <= 125 mA 120 V AC |
| Marking | CE |
| Voltage Range | 0...132 V |
| Current State 0 Guaranteed | <= 2 mA |
| Input Voltage Limits | 85...132 V |
| Response Time |
|
| Isolation Between Group | 1780 V AC |
| Net Weight | 0.284 kg |
| Voltage State 0 Guaranteed | <= 20 V |
| Current State 1 Guaranteed | >= 10 mA |
| Discrete Input Logic | positive |
| Local Signalling | for channel status 16 LEDs |
| Input Resistance |
|
| Width | 125 mm |
| Depth | 47.5 mm |
| Voltage State 1 Guaranteed | >= 74 V |
| Rohs Exemption Information | Yes |
| Mercury Free | Yes |
| Environmental Disclosure | ENVPEP1403005EN |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Weee | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| China Rohs Regulation | X |
| Circularity Profile | ENVEOLI1403005EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Product Certifications |
|
| Ambient Air Temperature For Operation | 0-60 °C |
| Resistance To Electromagnetic Fields | 10 V/m 80...1000 MHz IEC 801-3 |
| Ambient Air Temperature For Storage | -40-85 °C |
| Relative Humidity | 95-95 % without condensation |
| Resistance To Electrostatic Discharge |
|
| Operating Altitude | <= 16404.2 ft (5000 m) |
